CAT CAT305.5E2
Prezzo (IVA esclusa)
Stampa
INFORMAZIONI
Categoria
Miniescavatori
Marca/modello
CAT CAT305.5E2
Anno di costruzione
2024
Ore di utilizzo
450 h
Condizioni
Rigenerato
Paese
Cina
Valutazione generale
1
2
3
4
5
Mascus ID
77BC2619
PREZZO
Scegli la valuta
DETTAGLI
Tipo
Gasolio
Contratto di assistenza
Sì
Proprietari precedenti
1
Condizione sottocarro
good
Peso lordo
5.500 kg
Classe di emissione
Fase V
Track width
400 mm
Capacità benna
0,22 m3
Dimensioni trasporto (LxLxH)
576519502.54 m
Colore originale
YELLOW
Lunghezza avambraccio/barra
960 mm
Motore
Cat C2.4 DI
Potenza motore
34,1 kW (46,4 hp)
Produttore motore
JAPAN
Condizioni Info/Garanzia
good
Nazione di produzione
Giappone
Condizioni di consegna
FOB, CIF, EXW
Certificati
EPA, CE, ANSI, AS, CSA, EAC GOST, TRUA, JIS, TÜV, ASME
Accessori
All the auxiliary accessories can be provided for you. The above information is for reference only, and the specific details need to be confirmed with the factory.
Accessori
Benna ramaglie
Aria condizionata
Impianti idraulici aggiuntivi
AdBlue
attacco rapido
Guidacingoli
Staccabatteria
Attrezzatura opzionale
Diesel heater
Joystick control
Benna da scavo standard
Benna per cavi
Benna da scavo trapezoidale
Inclinazione idraulica
Depth control
Altre informazioni
The performance parameters of the Caterpillar CAT305.5E2 excavator are as follows:
1. **Overall Dimensions of the Machine**
- Total transportation length: 5765mm, total transportation width: 1950mm, total transportation height: 2540mm, minimum ground clearance: 628mm, rear swing radius: 1580mm, total track length: 2440mm, track gauge: 1550mm, track shoe width: 400mm, center distance between idler wheels: 1920mm.
2. **Operating Weight**
- The operating weight of the whole machine is 5400kg.
3. **Bucket Capacity**
- The bucket capacity is 0.22 cubic meters.
4. **Power System**
- Engine model: Cat C2.4 DI, rated power: 34.1kW, cylinder bore: 87mm, stroke: 102.4mm, displacement: 2.4L.
5. **Performance Parameters**
- Swing speed: 10.5rpm.
- Gradability: 50%.
- Bucket digging force: 35.0kN.
- Stick digging force: 27.2kN.
- Maximum drawbar pull: 40.2kN.
- Travel speed: 4.3/2.8km/h.
- Swing torque: 13.9N·m.
6. **Hydraulic System**
- Maximum main pump flow: 140L/min. The type of the main pump is a load sensing hydraulic system equipped with a variable displacement piston pump, and the working hydraulic circuit pressure is 25MPa.
7. **Oil Capacity**
- Fuel tank: 78L, hydraulic oil tank: 58L, engine oil change capacity: 9.5L, coolant: 9.8L.
8. **Working Range**
- Maximum digging radius: 5955mm.
- Maximum digging depth: 3720mm.
- Maximum digging height: 5460mm.
- Maximum unloading height: 3835mm.
- Maximum vertical digging depth: 2210mm.
9. **Bulldozer Blade Parameters**
- Lifting or pushing depth: 365mm/480mm, width×height of the bulldozer blade: 1950mm×360mm.
