CAT SR4B-GD

1843 kVA 1475 kW Natural Gas Generator SR4B-GD w/ Engine 3516C Title: 1843 kVA 1475 kW Natural Gas Generator SR4B-GD w/ Engine 3516C SKU: 138143 Model: SR4B-GD Year: 2012 Condition: Used S/N: G5Z01287 GeneralHorsepower:1978hp Fuel Type:Natural Gas Hours:27582.4 ElectricalkVA:1843kVA Voltage:400volts Phase:3-phase Made In: UNITED STATES Dimensions: 122.00 (H) x 118.00 (W) x 480.00 (L) inches Overhaul done at 26210 hours Ran for 1300 hours after overhaul Currently set for 50hz but can bump frequency up to 60hz Engine: - Caterpillar 3516C - Advertised power: 1622 kW // 2175 hp - Full load speed: 1500 RPM - Comp. ratio: 11.3:1 Overhaul Job Description: - Engine Major Overhaul - The cylinder block of generator set NO.5 is installed - Replaced main and rod bearings, piston rings, thermostat, and other wear parts - Replaced all seals on the unit; -Replaced 16 pistons and 4 cylinder liners - Repaired the cylinder head, parts not replaced; -Replaced two water pumps with REMAN parts - Repaired the oil pump - Cleaned and pressured test the oil cooler - Visually inspected the turbocharger. Left turbocharge used again, right turbocharge to be repaired - The coupling has been damaged and continues to be used without replacement Generator Maintenance: - It used the generator of the NO 5 genset set after maintenance - Replaced front and rear bearings and grease seals - Replaced front and rear bearing outer rings - Performed laser cladding on the rear ends of the main shaft - Performed VPI (Vacuum Pressure Impregnation) insulation treatment and drying - Conducted rotor dynamic balance test - Conducted overall performance testing Shaft Alignment Check: - Engine and Generator Shaft Alignment Radiator Check: - The water tank of genset 5 was installed into genset 6 - Radiator Disassembly, Reassembly, and Cleaning Generator Set D&A: - Continued to use the container of generator Set 6 - Generator Set Entry and Exit from the Container Overall Performance Testing: - Tested according to Caterpillar test standard 349-6498 (see attachment for details), with a maximum load reaching 60%. As all cylinder heads installed are manually refurbished on site, please note that the long-term load must not exceed 60%
