Putzmeister M42-4

Prezzo (IVA esclusa)

Images24Videos1
Putzmeister M42-4 Autopompe per calcestruzzo
Putzmeister M42-4 Autopompe per calcestruzzo
FavoritePreferito
shareCondividi
Save searchSalva ricerca
Stampa

INFORMAZIONI

Categoria
Autopompe per calcestruzzo
Marca/modello
Putzmeister M42-4
Anno di costruzione
2014
Ore di utilizzo
3.000 h
Condizioni
Ricondizionato,Rigenerato
Paese
Cina
Valutazione generale
1
2
3
4
5
Mascus ID
C8CCEE59

PREZZO

Scegli la valuta

DETTAGLI

Stock interno nr.
AICPT010
Numero di sezioni del braccio
5
Ultima ispezione
2024-09-26
Peso lordo
26.000 kg
Lunghezza del braccio
400 cm
Sbraccio orizzontale
3.730 cm
Massima distanza in verticale
4.160 cm
Movement type
Static
Pump power type
Gasolio
Pump power
300 kW
Dimensioni trasporto (LxLxH)
11500 x 2500 x 4200 mm
Classe di emissione
Fase V
Produttore motore
Ergonic3. EU Version
Tipo di pompa
Pistone
Produttore telaio
Mercedes Benz
Marca pneumatico
Mercedes Benz
Nazione di produzione
Cina
Condizioni di consegna
FOB, CIF
Certificati
EPA, CE, TÜV
Accessori
Technical Details General Information Arms 5 Folding Type RZ-Folding Vertical Reach 41.6 m Horizontal Reach gross 37.3 m Horizontal Reach net 34.5 m Reach Depth 31 m Unfolding Height 8.6 m Slewing Range 365 degree End Hose - Length 4 m Delivery Line (DN, Pressure) DN125/5.5 / 85 mm/bar Support width Standard (front-rear) 7.5 / 8.3 m Support width OSS (front-rear) 5.0 / 6.4 m Support width iSC (front/rear) 2.6-7.5 Length x Width x Height 11.35 x 2.5 x 4 mm Total Weight (approx.) under 32000 kg Configuration Concrete Pump .17 iLS Concrete Pump .16 H LS Concrete Pump .16 H Delivery Cylinder Diameter - Stroke Length 250/2100 mm Output (piston side) 170 m³/hr Delivery Pressure (piston side) 85 bar Strokes (piston side) 27
Altre informazioni
The Putzmeister M42-5 truck-mounted concrete pump has improved maneuverability and weight indices for 4 axle chassis. In Europe the M42-5 is equipped with iSC full flexible support and Ergonic 3 control. For countries outside of Europe it is equipped with the OSS support system, which allows you to work in a limited workspace. The concrete pump length is less than 12 meters, and it weighs less than 32 tons. Key Features A gross weight of less than 32 t includes sufficient reserves for payload and operating materials Smooth 5-arm placing boom, thanks to intelligent laying of the delivery line and the balanced development of the steel structure Efficient work through consistently clever ergonomic design Even better safety through closer consideration for current standards and guidelines Service-friendly as a result of its optimised accessibility and consistent bolted concept Lower service costs thanks to maintenance-free components, fewer special components (only 3 standard deliMostra altri

Achieve Innovations

5F Building 4, No.28, (M) Fuyuan Road, Kaifu Dist 410003 Changsha Hunan 湖南 Cina
